Anhui Huihuang Chain Transmission Co., Ltd. is one of the leading manufacturers and suppliers of s type agricultural machinery chain in China, featured by quality products and good service. If you're going to wholesale advanced s type agricultural machinery chain made in China, welcome to get pricelist and free sample from our factory. We also accept customized orders.
S-type Steel Agricultural Chains | Common Standard Models
S-type steel agricultural chains are widely used for farm machinery, harvesters, conveyors and field transport equipment. Below are mainstream specifications classified by pitch and model.
Standard S Series (Short Pitch)
S32: Pitch 19.05 mm 3/4"
S42: Pitch 22.23 mm 7/8"
S45: Pitch 25.40 mm (1")
S52: Pitch 28.58 mm 11/8"
S55: Pitch 31.75 mm 11/4"
S62: Pitch 38.10 mm 11/2"
S77: Pitch 41.28 mm
S88: Pitch 50.80 mm (2")
S Series with Attachments (Most Popular for Agriculture)
Equipped with standard attachments for carrying crops, straw and materials: S32F, S42F, S45F S52F, S55F, S62F S77F, S88F
S-Type Steel Agricultural Chain | Professional Selection Guide
Correct selection of S-type steel agricultural chains is essential to ensure stable operation and long service life of farm machinery under harsh working conditions. These specially structured agricultural chains feature excellent wear resistance, impact toughness and anti-corrosion performance, ideal for dusty, muddy and high-frequency farm operation scenarios.
Chain selection mainly depends on equipment type, load weight and working speed. For light-duty grain conveying, seedling machines and small harvesting equipment, standard small-pitch models such as S32, S42 and S45 are the optimal choices, offering flexible transmission and low operational consumption. For medium-load machinery including combine harvesters and crop balers, S52, S55 and S62 with higher tensile strength are widely adopted to withstand continuous material impact and friction.
For heavy-duty farm equipment working in severe environments, heavy reinforced seriesHS45, HS55, HS62 are strongly recommended.
They adopt thickened chain plates and optimized heat treatment to resist overload operation and reduce fatigue damage.
Meanwhile, models with F-type attachments can be selected according to installation demands, perfectly matching crop conveying and material lifting structures.
All our S-type agricultural chains follow standard pitch specifications. Scientific model selection effectively avoids chain elongation, jamming and breakage, lowering maintenance costs and improving overall working efficiency of agricultural machinery.
