Anhui Huihuang Chain Transmission Co., Ltd. is one of the leading manufacturers and suppliers of pintle chain in China, featured by quality products and good service. If you're going to wholesale advanced pintle chain made in China, welcome to get pricelist and free sample from our factory. We also accept customized orders.
Products Description
A sturdy non-roller conveyor chain made of interlocking open-barrel links joined by solid pins is called a pintle chain. This heavy-duty chain, also known as a case conveyor pintle chain, is designed specifically to move cartons, plastic totes, packaged goods, bulk grain, and agricultural materials via various material handling systems. It is a great option for packaging lines, warehouse conveyors, and farm harvesting equipment because of its open-barrel design, which provides smooth articulation, outstanding debris resistance, and dependable performance even in dusty, unclean operating environments.
The 620, 720, 820, 920, and 1020 series are common standard sizes. For agricultural and bulk conveying applications, steel pintle chain types 667X, 667H, and 667XC are also commonly used in addition to these standard standards.
For low-load conveying applications, the 667H is the affordable light-duty choice. The 667XC is a modified special-profile derivation of the 667X that is optimized to mate with bespoke sprockets for matching OEM replacement scenarios. The 667X is the universal heavy-duty standard variant that is available worldwide and is commonly installed on combine harvesters and manure spreaders.
Our pintle chains offer consistent tensile strength, a long service life, and less maintenance since they are expertly made to industry standards. Both regular supply and custom manufacture based on your technical drawings or samples are supported. We can offer appropriate, reasonably priced pintle chain products, whether you need new chain solutions for production line upgrades or aftermarket replacement chains for current conveyors
Steel Pintle Chain Specification Table
| Chain No. | Pitch P (mm / inch) | Inner Width b1 (mm) | Pin Diameter d2 (mm) | Link Plate Height h2 (mm) | Plate Thickness T (mm) | Min. Ultimate Tensile Strength (kN) | Weight per Meter (kg/m) | Core Feature |
| 667H | 55.80 / 2.196" | 25.4 | 7.92 | 22.23 | 3.18 | 43 | 1.7 | Light-duty basic model, low cost, for light agricultural conveying |
| 667X | 57.15 / 2.250" | 26.6 | 11.1 | 23.8 | 4.3 | 66.7 | 2.98 | General heavy-duty standard type, widely used in harvesters & manure spreaders |
| 667XC | 57.15 / 2.250" | 26.6 | 11.1 | 23.8 | 4.3 | 66.7 | 2.98 | Modified version of 667X with special contour, for specific matched sprockets |
Attachments & Scraper Customization (H2)
A1 Attachments: For light to medium scraper flights, one side of the lug is bent.
K1 Attachments: Heavy-duty flight bar bolting with bent lugs on both sides.
C5B/C10 Attachments: Heavy agricultural pushers designed for feed wagons and manure spreaders.
Custom Scraper Bars: Angle irons, flat bars, or specially made cleats that are manufactured in accordance with your technical specifications.
Limitations
Long-term exposure to mud and water causes carbon steel components to rust. After operation, routine lubrication and cleaning are necessary. Hinge abrasion will be accelerated by sand and gravel. Chain elongation will be permanent as a result of overload operation.
Application Scenarios & Selection Guide
H2: Applications in Industry and Agriculture
1： Composting and Fertilizer Handling:
To avoid binding and chain jumping, the open-barrel joint design automatically removes organic material from the sprocket tooth root.
2 ：Manure spreaders and feed wagons:
They can withstand shock start-stops in heavy agricultural loads thanks to their exceptional impact load resistance.
3 ：Spreaders for salt, sand, and fertilizer:
Surface treatments that prevent corrosion can withstand harsh chemical and road conditions.
H3: The Four-Step Selection Process for Choosing the Correct Pintle Chain
1 ：Evaluate environmental factors:
Steel Pintle is better for heavy dynamic loading and tensile shock resistance; Cast Pintle is better for severe wet/chemical corrosion.
2 ：Calculate Working Load:
Determine operating Load by contrasting operating strength with chain speed, conveyor material weight, and safety factors (recommended ≥ 5:1).
3 ：Specify Attachment Pattern：
Determine the necessary attachments (K1 every fourth pitch, for example) and bolt spacing.
4 ：Match Sprocket Profiles:
To prevent premature wear, make sure your drive assembly's pitch diameter and tooth profile match.
