Anhui Huihuang Chain Transmission Co., Ltd. is one of the leading manufacturers and suppliers of p125 pallet tunnel chain in China, featured by quality products and good service. If you're going to wholesale advanced p125 pallet tunnel chain made in China, welcome to get pricelist and free sample from our factory. We also accept customized orders.
Basic Parameters
|
Parameter |
Specification |
Unit |
|
Chain Number |
P125 Pallet Tunnel Chain |
- |
|
Pitch (P) |
125 |
mm |
|
Roller Type |
Plastic roller (blue, low-friction) |
- |
|
Plastic Roller Diameter (d₁) |
40 |
mm |
|
Plastic Roller Width (b₁) |
30 |
mm |
|
Attachment Type |
Pallet support block (white engineering plastic) |
- |
|
Support Block Size (L×W×H) |
60 × 20 × 15 |
mm |
|
Pin Diameter (d₂) |
16 |
mm |
|
Plate Height (h₂) |
45 |
mm |
|
Plate Thickness (t) |
6 |
mm |
|
Ultimate Tensile Strength (min) |
≥80 |
kN |
|
Working Load (typical) |
≤15 |
kN |
|
Weight per Meter |
≈12 |
kg/m |
|
Material |
Stainless steel (304/316) or alloy steel |
- |
|
Surface Treatment |
Polished / passivated (for stainless steel) |
- |
Description
Our P125 pallet tunnel chain is a heavy-duty conveyor solution tailor-made for tunnel ovens, drying lines and continuous pallet handling systems. It is built to withstand long-hour running and harsh working conditions in thermal processing environments.
Equipped with low-friction plastic rollers and wear-resistant support blocks, the chain delivers ultra-smooth, quiet and steady movement during pallet transportation. These components effectively reduce friction loss and slow down abrasion, maintaining consistent performance all the time.
Adopting premium stainless steel as the main material, it boasts outstanding anti-rust and anti-corrosion properties. This greatly extends its service life even under sustained high temperatures. Durable, reliable and low-maintenance, this chain is an ideal choice for industrial thermal conveying and automated pallet transport applications.
Our Service
We provide all-round professional services for P125 pallet tunnel chains. We strictly follow industry standards for production and full quality inspection before delivery. Customized sizes and accessories are available to fit your tunnel oven and drying line requirements. Our team offers timely technical guidance for installation and maintenance. We also guarantee reliable after-sales support, helping you solve operational problems efficiently. Choose us for stable products and worry-free service.
