LL Series Leaf Chains – Standard Models & Technical Parameters
(ISO 4347 / DIN 8152, Light-Duty Leaf Chains)
LL series are light-duty leaf chains for lifting/balancing (forklifts, elevators, cranes). Below are common sizes with English parameter table.
Our Standard Models & Specifications
|
Chain No. |
PitchP (mm) |
Plate Lacing |
Plate Depthh₂ (mm) |
Plate Thicknesst (mm) |
Pin Diameterd₂ (mm) |
Ultimate Tensile Strength (kN) |
Weight(kg/m) |
|
LL0822 |
12.7 |
2×2 |
10.6 |
1.3 |
4.45 |
36 |
0.42 |
|
LL0844 |
12.7 |
4×4 |
10.6 |
1.3 |
4.45 |
72 |
0.84 |
|
LL0866 |
12.7 |
6×6 |
10.6 |
1.3 |
4.45 |
108 |
1.24 |
|
LL0888 |
12.7 |
8×8 |
10.6 |
1.3 |
4.45 |
144 |
1.64 |
|
LL1022 |
15.875 |
2×2 |
13.7 |
1.6 |
5.08 |
25.5 |
0.54 |
|
LL1044 |
15.875 |
4×4 |
13.7 |
1.6 |
5.08 |
51 |
1.06 |
|
LL1066 |
15.875 |
6×6 |
13.7 |
1.6 |
5.08 |
76.3 |
1.57 |
|
LL1088 |
15.875 |
8×8 |
13.7 |
1.6 |
5.08 |
101.9 |
2.1 |
|
LL1222 |
19.05 |
2×2 |
16 |
1.85 |
5.72 |
33.2 |
0.73 |
|
LL1244 |
19.05 |
4×4 |
16 |
1.85 |
5.72 |
66.4 |
1.44 |
|
LL1266 |
19.05 |
6×6 |
16 |
1.85 |
5.72 |
99.7 |
2.15 |
|
LL1288 |
19.05 |
8×8 |
16 |
1.85 |
5.72 |
132.9 |
2.84 |
|
LL1622 |
25.4 |
2×2 |
21 |
3.1 |
8.28 |
76.3 |
1.52 |
|
LL1644 |
25.4 |
4×4 |
21 |
3.1 |
8.28 |
152.6 |
3.04 |
Key Notes
Lacing: 2×2, 4×4, 6×6, 8×8 = inner×outer plates.
Material: High‑grade alloy steel, heat‑treated; stainless steel (SS) option available.
Application
LL series leaf chains are mainly designed for lifting and balancing systems.
They are widely applied in forklifts, stackers, overhead cranes and warehouse handling equipment.
These chains perform stably under frequent reciprocating loads.
They also suit automotive workshops, logistics terminals and industrial lifting machinery.
With strong tensile performance, they serve as reliable transmission parts for various material handling scenarios.
