Anhui Huihuang Chain Transmission Co., Ltd. is one of the leading manufacturers and suppliers of c2080-2-20t type b in China, featured by quality products and good service. If you're going to wholesale advanced c2080-2-20t type b made in China, welcome to get pricelist and free sample from our factory. We also accept customized orders.
Basic Identification
|
Item |
Specification |
|
Model |
C2080-2-20T Type B |
|
Also known as |
2080B20-2 |
|
Matching chain |
C2080 / A2080 double‑pitch roller chain (double‑row) |
|
Structure |
Double‑row, 20 teeth, Type B (single hub) |
|
Standards |
ANSI B29.4, ISO 1275‑1 |
Dimensions (20 Teeth)
|
Parameter |
Value (inch) |
|
Number of teeth |
20 |
|
Pitch |
2.000" (50.80 mm) |
|
Pitch diameter |
6.472" |
|
Outside diameter |
6.910" |
|
Caliper diameter |
5.845" |
|
Tooth width (per row) |
0.575" |
|
Total face width |
~1.200" |
|
Standard bore |
1.000" |
|
Hub diameter |
4.250" |
|
Hub length |
1.500" |
Core Features
This sprocket adopts a sturdy double-row structure, which effectively boosts overall load capacity and realizes even force distribution during operation. It avoids excessive stress concentration and delivers more stable performance under medium and heavy working loads.
Equipped with practical Type B single hub, it enables firm and reliable mounting on the shaft. The structure simplifies installation and disassembly work, bringing great convenience for daily assembly and maintenance.
All teeth are processed with high-precision machining, ensuring perfect and smooth engagement with matched chains. This design greatly reduces running vibration and noise for steady long-term operation.
Complying strictly with ANSI and ISO industrial standards, the product shares full interchangeability with standard C2080 sprockets. It can serve as a direct replacement without extra modification, being a reliable and cost-effective transmission part for industrial use.
