Anhui Huihuang Chain Transmission Co., Ltd. is one of the leading manufacturers and suppliers of stainless steel conveyor sprocket in China, featured by quality products and good service. If you're going to wholesale advanced stainless steel conveyor sprocket made in China, welcome to get pricelist and free sample from our factory. We also accept customized orders.
Basic Information
| Product Name |
Stainless steel conveyor sprocket |
| Rows | Simplex, Duplex & Triplex strands |
| Pitch range | 6.35mm-63.5mm |
| Product grouping | Driving Chains |
product properties
| USES | Transportation Chain |
| Material | Alloy/Carbon Steel/Stainless Steel |
| Transport Packaging | Export Package |
| Supply type | ODM&OEM |
Product number
ANSI/ASME Standard: #25, #35, #40, #50, #60, #80, #100, #120; C2040, C2050, C2060, C2080 (double pitch conveyor chains)
ISO/DIN Metric: 06B, 08B, 10B, 12B, 16B, 20B; 08A, 10A, 12A, 16A
Double-pitch models like C2080 (50.8mm pitch) are widely used in long-length conveyor systems, with stainless steel sprockets available in single/duplex/triple-strand configurations.
Key Construction Specifications
We offer a comprehensive range of structural configurations to meet diverse industrial transmission demands. Our sprockets are available in simplex, duplex, triplex and custom multi-strand versions. Multi-strand designs deliver enhanced load capacity, perfectly catering to heavy-duty operating conditions.
For tooth count, standard options cover 10 to 60 teeth, while customized tooth quantities are also supported. Most conveyor sprockets adopt 12T to 30T, which ensures stable chain engagement and smooth running performance.
Three mainstream hub styles are provided for flexible selection. Type A is a plain plate without hub, featuring pilot bore for further machining, best suited for light-duty and compact installations. Type B comes with a single-side hub, enabling reliable shaft mounting even in space-restricted areas. Type C is equipped with dual hubs on both sides, standing out for high-load and high-speed working scenarios.
In terms of bore choices, we supply pilot bore for on-site reprocessing, finished bore fitted with keyway and set screws, as well as taper bore for quick and convenient assembly. All specifications follow industry standards, ensuring great compatibility and reliable performance for various equipment.
