Anhui Huihuang Chain Transmission Co., Ltd. is one of the leading manufacturers and suppliers of stainless steel rod chain in China, featured by quality products and good service. If you're going to wholesale advanced stainless steel rod chain made in China, welcome to get pricelist and free sample from our factory. We also accept customized orders.
Structure Analysis
Side Driving Chains Matched stainless steel roller chains on two sides serve as traction components, meshing with driving sprockets. Chain models can be customized according to load.
Horizontal Solid Support Rods (Core Component) Polished solid stainless steel rods penetrate outer chain plates evenly to form the carrying surface. Rod spacing is adjustable to control material leakage.
Modular Design Chains can be connected endlessly for longer conveying distance. Rods are detachable; worn rods can be replaced individually instead of whole chain.
Key Features & Advantages
Excellent Permeability for Draining & Drying Uniform gaps between rods enable smooth air flow, water spraying, draining and oil removing, ideal for washing and drying processes.
Easy Cleaning & Low Material Blockage Open structure without dead corners, convenient for high-pressure cleaning, compliant with food hygiene requirements.
Gentle Conveying, Less Product Damage Smooth round rods avoid scratches on fruits, packages and fragile workpieces.
High Temperature & Corrosion Resistance SUS304 withstands regular high temperature and washing conditions. SUS316L performs well in salty and weak acid environments.
Low Maintenance Cost Detachable rods allow partial replacement, saving overall equipment maintenance expense.
Limitations
Not suitable for ultra-fine powder materials, small particles will fall through gaps.
Long rods may bend under heavy load; thicker rods and tighter spacing are required for heavy-duty transport.
Medium & low running speed recommended to avoid fatigue abrasion at rod ends under high-speed impact.
Typical Applications
Fruit & vegetable washing lines, food baking & drying conveyors, quick-freezing processing, glass bottle & can cleaning lines, heat treatment cooling conveyors, slaughter processing equipment, lithium battery cleaning lines, hardware phosphating washing lines.
Selection & Custom Options
Material: Standard SUS304; SUS316L for salty and corrosive conditions
Chain Model: Different roller chain sizes selected based on load capacity
Rod Parameters: Rod diameter and center distance can be customized
Extra Options: Stopper blocks on rods, side guard plates, anti-slip structures
